Model JS-DC-DC MB9

Item Specification

Energy Storage System

Energy Capacity 200KWh (Lithium Iron Phosphate Battery)

Battery Type Lithium Iron Phosphate (LiFePO₄)

Storage Voltage DC 500-800V

Cycle Life ≥6000 cycles (80% capacity retention)

Storage Efficiency ≥95% (Charge-Discharge Efficiency)

Charging System

Max Charging Power 180kW (Single Gun) / Dual-Gun Power Allocation Customizable

Output Voltage Range DC 200-1000V (Compatible with CCS2)

Output Current Range 0-250A

Charging Connector CCS2 (European Standard) + Optional Type 2 AC Connector

Charging Efficiency ≥95% (DC Output)

Electrical & Safety

Input Voltage 3-Phase AC 380V±15%, 50/60Hz

Protection Class IP54 (Main Unit) / IP55 (Coupled Gun)

Compliance CE Certification (EN 61851-1, EN 61851-23)

Safety Features Overvoltage

/Overcurrent/Overtemperature Protection, Leakage Protection, Fire & Explosion Prevention, Emergency Stop

Communication & Control

Communication Protocol ISO 15118 (DC Charging), OCPP 1.6J (Smart Scheduling)

Monitoring System Local Touchscreen + Remote Cloud Platform (Real-Time Data Monitoring, Fault Alarm)

Environmental Parameters

Operating Temperature -10℃ ~ +60℃

Storage Temperature -20℃ ~ +70℃

Relative Humidity 5% ~ 95% (Non-Condensing)

Altitude ≤2000m

Mechanical Parameters

Dimensions 2600×1350×1600mm (L×W×H)

Weight ~2800kg

Installation Method Ground-Mounted
